Metal Anti-Acoustic And Impact Resistant Indoor Wall Cladding
Indoor wall cladding is constructed with phenolic resin panels installed by means of hardware hangers and other fittings. It can be fixed to brick walls or other wall surfaces, and can also be directly mounted on both sides of a metal frame to serve as partition walls in interior spaces.
Product Description
What is Indoor Wall Claddng?
Indoor wall cladding is constructed with phenolic resin panels installed by means of hardware hangers and other fittings. It can be fixed to brick walls or other wall surfaces, and can also be directly mounted on both sides of a metal frame to serve as partition walls in interior spaces.
What are the advantages and features of Indoor Wall Claddng?
Durable Interior Wall Cladding
Indoor wall cladding can easily give interior spaces any style and creativity you need, while resisting all kinds of damage you can or cannot imagine, thus truly combining humanistic and modern technology perfectly.
Excellent decorative properties
Environmentally friendly and healthy
Wear-resistant and scratch-resistant
High strength and impact-resistant
Easy to clean
Fire-resistant and flame-retardant
Corrosion-resistant
Mildew-proof and moisture-proof
Disassembled and easy to repair
Interior Wall Cladding installation
Low Maintenance Interior Wall Cladding
(1)Dry Hanging
The dry hanging method involves locking the hangers to the back of the wall panel and then hanging the wall panel on the horizontal keel of the frame structure.
The advantage of dry hanging is that it can be easily disassembled, facilitating the maintenance of the pipes behind it.
Currently, there are many different, yet largely similar, hardware options available for dry hanging systems in China.
Users can choose different hardware systems according to their needs, but the most basic requirement is that the hardware used in the dry hanging system should be made of materials that are not easy to rust and corrode, and have considerable strength. Our company uses T5/T6 grade aluminum.
| Wall cladding panel thickness | Vertical spacing of keel | Lateral spacing of keel |
| 8mm | <600mm | 400~450mm |
| 10mm | <650mm | 500~600mm |
(2) Bonding
Bonding method features easy construction and low cost. To achieve a firm bonding effect, special polyurethane adhesive shall be used. Prior to the curing of the polyurethane adhesive, double-sided tape may be applied to temporarily fix the wall panels.
| Wall cladding panel thickness | Vertical spacing of keel | Lateral spacing of keel |
| single span | multi-span | |
| 5mm | 400~450mm | <400mm |
| 6mm | 450~550mm | <600mm |
Whether using dry hanging or adhesive bonding, the following points must be paid special attention to:
1.Leave a certain gap between the two wall panels to allow for expansion and contraction (minimum 5mm).
2.Wall panels should be installed on a metal frame structure, and not directly on brick walls or plywood, etc.
3.The wall panel must not be in direct contact with brick walls, floors, or ceilings.
4.Ensure that there is a certain degree of air circulation between the wall panel and the wall.
